Overview

The INBAL PA1 Pressure Reducing Pilot Valve is a direct-acting, diaphragm-operated control valve designed to automatically regulate downstream pressure. It ensures stable and accurate pressure reduction even under fluctuating inlet conditions.

Key Features

• Direct acting pressure control operation
• Balanced single-seat design for high accuracy
• Stable performance under inlet pressure fluctuations
• Adjustable spring-loaded pressure setting
• Resilient sealing for positive shutoff
• Simple structure for easy maintenance
• Brass body with nickel-chrome plating

Applications

• Industrial pressure control systems
• Water distribution systems
• Process control pipelines
• Pumping and hydraulic systems
• Pressure regulation in industrial plants

Technical Specifications

• Model: PA1
• Manufacturer: INBAL
• Type: Pressure reducing pilot valve
• Operation: Direct acting, diaphragm actuated
• Design: Balanced single seat
• Maximum Working Pressure: 300 psi (21 bar)
• Temperature Range: up to 80°C (180°F)
• Material: Brass (nickel-chrome plated)
• Adjustment: Spring loaded
• Function: Pressure reduction control
